Metal Keypad, IP67

The MCAK304NSSLWPMMYLGKT is a 3 x 4 yellow/green illuminated Metal Keypad configured on a standard matrix layout and connection is via PCB pre-drilled 2.54mm solder terminals. It has each key lit by a LED producing a low level glow. It is supplied with a front fitting sealing gasket.

• Condition: Brand New
• IP67 Protection rating

• 200R Maximum contact resistance

• 2000000 Cycles per key life
• -20 to 60°C Operating temperature range
• Manufacturer Part No: MCAK304NSSLWPMMYLGKT
• Manufacturer: MULTICOMP
• Manufacturer Part No MCAK304NSSLWPMMYLGKT

• Contact Current Max: 20mA

• Contact Voltage DC Nom: 24V

• Keypad Output: Matrix

• Keypad Array: 3 x 4

• Housing Material: Metal

• No. of Keys: 12

• Panel Cutout Width: 46mm

• Panel Cutout Height: 57mm

General Specification:

• Contact rating : 20 mA, 24 V dc
• LED contact rating : Vmax = 4 V, Vnom = 3.5 V

• Maximum contact resistance : 200 ohms

• Life : 2,000,000 cycles per key

• Operating temperature : -20°C to +60°C

• Storage temperature : -40°C to +65°C
